Introduction to 5 Gallon Preform Injection Mold
The 5 gallon preform injection mold is specifically engineered for producing PET preforms for 18.9L (5-gallon) large-capacity water containers. Preforms produced using this 5 gallon preform mold undergo subsequent heating, stretching, and blow molding processes to become standard 5-gallon water containers.
These finished containers are the mainstream packaging solution for commercial and residential drinking water.
To accommodate manufacturers of varying production scales, KRMOLD 5 gallon preform mould supports customizable multi-cavity configurations. Standard specifications include 2, 4, 6, and 8-cavity layouts, fully meeting requirements ranging from small-batch pilot runs to large-scale mass production, thereby enabling efficient, stable, and standardized preform manufacturing.
Specifications of 5 Gallon Preform Injection Mold
| Application | Mineral Water Bottle |
| Resin Material | PET |
| Neck Finish | 55mm |
| Cavity Number | 2 (Depending on the design) |
| Cavity Material | S136H |
| Core Material | S136H |
| Mold Base | 4Cr13 |
| Hot Runner | In-house Brand |
| Anti-Crystallization | Not Included |
| Sample Provision | 5 Shot Samples |
| Target Life | 6 Million Cycles |
